Truck Scale Indicator with Printer

Truck Scale Indicator
Model: T6-4, T6-4A
Stainless Steel Housing
6-digit 30.5mm red LED
Dimensions: 320×200×180mm
Applications: Weigh Bridge, truck scale, platform scales etc.

Front Panel View

Specifications
Analog signal input range: 1 – 3 mV/V
Excitation voltage: 5V DC, up to 8, 350Ω load cells.up to 16, 700Ω load cells
A/D resolution: 1.5 million internal counts
A/D sampling rate: 60 times/second
Accuracy of measured weight can be temporary increased ten times
6-digit, 7-segment with a decimal point, 30.5 mm high LED display
Real-time clock and programmable date and lock to stop work
28 function keys menu driven calibration and configuration
Selectable display resolution
Selectable kg and t unit
Selectable digital filter value
Four non-linearity calibration points
Allow changing of indicator without recalibration
Lock display when overload is greater 130% FS  Auto zero range
Store and recall up to 100 vehicle numbers and tares, 1000 weighing records Optional manual or automatic printout
Daily, monthly and statistics reports by time, vehicle or goods number
RS-232C interface with 2 transmit outputs, selectable baud rate: 1200, 2400, 4800, 9600
